DuraClik 2.00mm Wire-to-Board Connector System
DuraClik 2.00mm-Pitch Wire-to-Board SMT Connectors provide superior electrical contact reliability, space savings and high PCB retention force capability. These connectors are designed to improve connection security and performance in challenging environments subject to high vibration and high temperatures.
Features and Advantages:
Ensures secure connector-to-PCB header retention:
Robust secondary lock variants can withstand an upward pull force of 100N (10kgf) to meet automotive vibration requirements.
Confirms correct and secure mating: durability + click (sound) = DuraClik
An audible click sound on mating and built-in inertia lock available in versions up to 15 circuits help ensure a reliable connection.
Offers greater design flexibility
Different header options of 2 to 15 circuits—in vertical and horizontal configurations—are available.
Provides secure mating and space savings; prevents latch breakage from wire tangling
An inner positive lock prevents unintended disconnection.
Delivers automotive-grade robustness
The ISL receptacle conforms to LV214 (S2 vibration), ES91500-03 and SAE/ USCAR-21 standards.
Permits use in high-level automotive passenger compartment applications
DuraClik's operating temperature range of -40 to +130°C ensures reliability in challenging conditions.
Applications:
Automotive:
Headlights |
Gearshifts |
Rearview mirrors |
Rear combination lamps |
Meter systems Door modules |
Seat adjusters |
Steering switches |
Navigation systems |
Sensors |
Electric Vehicle:
Battery management systems (BMSs) |
Vehicle Connectivity |
DC-DC converters |
Inverter fastener components |
Telematics modules |
Onboard chargers |
Head-up displays |
Power distribution units |
|
Commercial Vehicle:
Tractors |
Cranes |
Industrial machinery |
Consumer:
White goods
LED lighting
IH cooking heaters
Vending/gaming machines
Energy storage systems
|
|
Read more about DuraClik 2.00mm Wire-to-Board Connector System.
