Power Versa-Lock Connectors
|
DESIGNED FOR VERSATILITY AND PERFORMANCE
TE Connectivity's (TE) Power Versa-Lock connector system offers a high-performance, wire-to-wire power solution with IP67 rated protection from water and dust. These connectors have a compact 5.0mm pitch design and use tab and receptacle contacts to provide four points of contact for enhanced reliability. They are available with optional terminal position assurance (TPA) and back cover accessories, which both help ensure proper assembly and provide additional retention for reliability. The Power Versa-Lock series also offers a special twist and lock cap, designed for refrigeration applications, which allows condensation to drip away from the connection.
|
 |
|
Electrical:
- Voltage Rating: 600V AC
- Current Rating: 15A
Materials:
- Flammability Ratings:
- UL 94 V-0
- Glow Wire Test (GWT)*
- Operating Temperature: -30 to +130°C
|
Mechanical:
- Pitch: 5.00mm
- Wire Size: 26-14AWG
- Positions: 1-4, 6, 9
- Configurations:
- Wire-to-wire
- Wire-to-panel
- Ingress Protection: IP67
|
Learn more click here
Key Features:
- IP67 rated protection against water and dust
- Perimeter seals offer low mating force for enhanced ergonomics
- Optional TPA (for use with unsealed version) and back covers (for use with sealed version) help ensure proper assembly
- Tab and receptacle contact system helps provide higher reliability
- Mounting clip secures free hanging connectors where panel mounting is not an option
- Innovative twist and lock (TNL) cap offering were designed to allow moisture to drip away from the connection in refrigeration applications
Product Specifications：
Applications：
For more POWER VERSA-LOCK CONNECTORS recommendations or customizations, please feel free to contact your sales team at Heilind Asia Pacific.
|
